- It can measure both compression and tension springs
- Easy operate for condition setting and product number registration on touch panel screen
- Product number registration can be registered up to 100th
- Spring rate, Free length, Solid hight、Pre- tension, Step operation(Up to 3 steps)
- Printing results by built-in Printer
- Optional PC software available
- The SW series supports Japanese, English, Simplified Chinese and Traditional Chinese.
- The language can be selected by touch panel operation, It useful for globalization of production bases.
Specifications
| SWT-100 | SWT-200 | SWT-500 | |
| Capacity | 1kN | 2kN | 5kN |
| Force Resolution | 0.01N | 0.1N | 0.1N |
| Measuring range | 0.5% to 95% F.S.( At the time of Force measurement or take Spring rate) | ||
| Force Acuracy | ±0.2% F.S. | ||
| Unit of measurment | N（only in JAPAN）At overses it can use unit kg and lb | ||
| Test Speed | 5 to 600 mm/min | ||
| Max measurable length | 600mm | ||
| length resolution | 0.001㎜ | ||
| Length accuracy | ±0.1㎜（with in the range 500mm） | ||
| Compression plate diameter | 150mm | ||
| Hook for tensil test | 1type | Optional | |
| Size | W876×D450×H1426 mm | W876×D450×H1513 mm | |
| Weight | Approx. 190kgs | Approx. 250kgs | |
| Power Supply | Selectable frorm AC100 to 110V , AC200 to 220V | ||
Print function
Printing results by built-in Printer.
It can Print [Date] resisterd [Model number] [Value] [OK or NG].
＜Example of printing＞
Operation panel
＜Measurement Screen＞
Set the Step operation, set the comparate value.
＜Test Condition＞
Set the measurement condition.
It can save as Item number.
＜Item number resist＞
It can resist the Item number.
It can set up to 100th.
※All specifications may be changed without a notice
